Fluke TiX580 | 640×480 Articulating Thermal Camera with 5.7-Inch Touchscreen

Thermal inspection becomes difficult when equipment is above, below or behind structures that prevent comfortable camera positioning. The Fluke TiX580 Infrared Camera solves this problem with a lens assembly that rotates through 240° and a large 5.7-inch touchscreen, allowing thermographers to inspect challenging targets from more practical viewing angles.

Native infrared resolution is 640 × 480, while SuperResolution can produce images up to 1280 × 960. The camera measures from -20°C to 1000°C and provides thermal sensitivity down to 50 mK. LaserSharp Auto Focus uses a built-in laser distance meter to help achieve accurate focus. IR-Fusion, radiometric video, optional smart lenses and Fluke Connect support detailed inspection, documentation and reporting.

Articulating Thermal Camera Selection Guide

Choose the TiX580 when an articulating lens and large 5.7-inch display provide a real advantage for inspecting hard-to-reach assets. For conventional pistol-grip inspection, Ti480 PRO may be more appropriate.

Market Relevance

The TiX580 suits Pakistani power plants, electrical utilities, petrochemical facilities, heavy manufacturing, and specialist thermography companies inspecting difficult-access assets. Kamadi Pakistan offers the Fluke TiX580 for advanced professional thermal inspection.

Key Features

• 240° rotating lens assembly

• 5.7-inch responsive touchscreen

• 640 × 480 native thermal resolution

• SuperResolution up to 1280 × 960

• LaserSharp autofocus with IR-Fusion


Technical Specifications

• Model: Fluke TiX580

• IR Resolution: 640 × 480

• SuperResolution: 1280 × 960

• Temperature Range: -20°C to 1000°C

• Thermal Sensitivity: 50 mK

• IFOV: 0.93 mrad

• Field of View: 34° × 24°

• Distance-to-Spot: 753:1

• Video: Standard and radiometric

• Connectivity: Fluke Connect / Wi-Fi


Applications

• Difficult-access electrical assets

• Power-generation equipment

• Predictive maintenance

• Industrial thermography

• High-temperature process inspection


Professional Tip: Use the articulating lens to improve inspection ergonomics rather than stretching or positioning yourself awkwardly around energized or elevated equipment.
