Fluke Ti480 PRO | 640×480 Thermal Camera with Super-Resolution to 1280×960

Detailed thermography of high-temperature or critical industrial assets requires both strong native resolution and the ability to capture subtle thermal differences. The Fluke Ti480 PRO Infrared Camera combines a 640 × 480 detector with software-based SuperResolution that captures and combines additional image data to produce thermal images up to 1280 × 960 pixels.

Its temperature range reaches 1000°C, while thermal sensitivity is specified at ≤50 mK at a 30°C target. LaserSharp Auto Focus and optional MultiSharp Focus help maintain image sharpness, and a built-in laser distance meter assists precise targeting. IR-Fusion adds visible-light context, while radiometric video, wireless remote operation, voice annotations and optional specialist lenses expand the camera beyond routine maintenance inspection into advanced thermographic analysis.

Advanced Professional Thermal Camera Selection Guide

Choose the Ti480 PRO when you need 640 × 480 native resolution, 1000°C measurement, improved 50 mK sensitivity and SuperResolution. The Ti401 PRO is appropriate when you need the same professional platform without these higher-end capabilities.

Market Relevance

The Ti480 PRO suits Pakistan's power generation, steel, cement, oil and gas, petrochemical, R&D, and specialist condition-monitoring teams that need detailed thermal analysis. Kamadi Pakistan offers the Fluke Ti480 PRO for advanced professional and high-temperature thermography.

Key Features

• 640 × 480 native thermal resolution

• SuperResolution up to 1280 × 960

• Temperature measurement to 1000°C

• LaserSharp and MultiSharp focusing

• Radiometric video and remote-control capability


Technical Specifications

• Model: Fluke Ti480 PRO

• IR Resolution: 640 × 480

• SuperResolution: Up to 1280 × 960

• Temperature Range: -20°C to 1000°C

• Thermal Sensitivity: ≤50 mK

• IFOV: 0.93 mrad

• Field of View: 34° × 24°

• Display: 3.5-inch, 640 × 480 touchscreen

• Focus: LaserSharp autofocus + manual

• Frame Rate: 9 Hz or 60 Hz versions


Applications

• High-temperature process inspection

• Power generation

• Heavy industrial thermography

• R&D temperature analysis

• Predictive-maintenance programs


Professional Tip: Use SuperResolution on stable targets where maximum detail matters; for rapidly changing thermal events, prioritize the appropriate native-frame capture mode instead.
