Fluke 805 FC | Vibration Meter with Bearing Condition & Infrared Temperature Measurement

Rotating machinery often develops excessive vibration long before a complete mechanical failure occurs. However, inconsistent handheld measurements can make it difficult to determine whether equipment condition is deteriorating. The Fluke 805 FC Vibration Meter provides repeatable vibration screening with an innovative sensor design that reduces variations caused by contact pressure and measurement angle.

It measures overall vibration from 10 Hz to 1000 Hz, covering acceleration, velocity and displacement, while Crest Factor+ evaluates bearing condition in the higher 4000–20,000 Hz range. A four-level severity scale helps maintenance personnel prioritize attention, and an integrated infrared thermometer adds surface-temperature information.

The instrument stores up to 3500 measurements and supports USB export for trending in Excel. Fluke Connect functionality provides additional condition-tracking capability in supported regions.

Industrial Vibration Meter Selection Guide

Choose the 805 FC for routine vibration screening, bearing assessment and trend monitoring. Select the Fluke 810 when automated diagnosis of specific mechanical faults is required.

Market Relevance

The Fluke 805 FC is especially useful in Pakistan's textile mills, cement factories, steel plants, sugar mills, fertilizer plants and industrial utilities, where rotating equipment operates continuously. Buy the Fluke 805 FC from Kamadi Pakistan for condition-based maintenance and early fault detection.

Key Features

• Overall vibration and bearing-condition screening
• Crest Factor+ technology
• Four-level condition severity indication
• Integrated infrared temperature measurement
• Measurement storage and data trending

Technical Specifications

• Model: Fluke 805 FC
• Overall Vibration Frequency: 10–1000 Hz
• Bearing Measurement Frequency: 4000–20,000 Hz
• Vibration Measurement Range: 0.01–50 g
• Acceleration Resolution: 0.01 g
• IR Temperature Range: -20°C to 200°C
• IR Temperature Accuracy: ±2°C
• Memory: Up to 3500 measurements
• Ingress Protection: IP54

Applications

• Pump vibration monitoring
• Electric motor condition screening
• Bearing deterioration assessment
• Fan and blower maintenance
• Rotating equipment inspections

Professional Tip: Measure vibration at the same machine location, direction and operating load during every inspection; consistent measurement conditions are essential for meaningful trend comparisons.
