Fluke 62 MAX | -30°C to 500°C Rugged Infrared Thermometer

Checking hot motors, bearings, electrical connections or HVAC components by direct contact can be inconvenient or unsafe. The Fluke 62 MAX Infrared Thermometer measures surface temperature from a distance, allowing maintenance teams to inspect equipment without placing a probe directly on the target.

Its temperature range covers -30°C to 500°C, with a 10:1 distance-to-spot ratio and single-laser aiming to help identify the measurement area. Adjustable emissivity supports different surface materials, while Min, Max, Average, and Differential modes help technicians compare thermal conditions rather than rely on a single instantaneous reading. The instrument responds in under 500 ms and is built for harsh maintenance work, with an IP54 enclosure and a 3 m drop rating. A large backlit display supports inspection in poorly lit equipment areas.

Infrared Thermometer Selection Guide

Choose the 62 MAX for general maintenance temperatures up to 500°C and a 10:1 optical ratio. Select the 62 MAX+ when you need a higher temperature range, faster response, and 12:1 optics.

Market Relevance

The Fluke 62 MAX is well suited to Pakistan's manufacturing plants, HVAC service, electrical maintenance, motors and pumps, food facilities and preventive-maintenance teams. Buy the Fluke 62 MAX from Kamadi Pakistan for rugged non-contact temperature inspection.

Key Features

• Non-contact temperature measurement to 500°C

• 10:1 distance-to-spot ratio

• Adjustable emissivity

• Min/Max/Avg/Difference measurement modes

• IP54 construction with 3 m drop resistance


Technical Specifications

• Model: Fluke 62 MAX

• Temperature Range: -30°C to 500°C

• Accuracy: ±1.5°C or ±1.5% of reading

• Distance-to-Spot Ratio: 10:1

• Response Time: <500 ms

• Emissivity: 0.10–1.00

• Laser: Single, Class 2

• Ingress Protection: IP54

• Drop Test: 3 m

• Battery: 1 × AA alkaline


Applications

• Motors and bearings

• Electrical connections

• HVAC equipment

• Preventive maintenance

• Process-equipment surface checks


Professional Tip: For shiny metal surfaces, do not rely on the default emissivity setting—adjust emissivity appropriately or measure a prepared high-emissivity reference area for a more representative temperature result.
