Fluke 375 FC | True-RMS AC/DC Clamp Meter with Fluke Connect & iFlex Compatibility

Industrial electrical systems increasingly combine motors, variable-frequency drives and non-linear loads, making dependable True-RMS measurement important for day-to-day troubleshooting. The Fluke 375 FC True-RMS AC/DC Clamp Meter is built for technicians who need current, voltage, resistance and frequency measurement in one connected industrial tool.

It measures up to 600 A AC/DC through the clamp jaw and supports the optional iFlex flexible current probe for AC measurements up to 2500 A, helping technicians work around large or difficult-to-access conductors. Voltage measurement extends to 1000 V AC/DC, while frequency and resistance functions broaden its use around motors and distribution equipment. Fluke Connect compatibility enables wireless viewing, logging and reporting, allowing measurements to be documented from the field and reducing the need to remain directly beside energized equipment.

Industrial Clamp Meter Selection Guide

Choose the 375 FC when you need 600 A AC/DC measurement, frequency testing and optional iFlex expansion. Select the 374 FC for more basic current and voltage work, or the 376 FC when direct jaw measurement approaching 1000 A is required.

Market Relevance

The Fluke 375 FC suits Pakistan's textile mills, cement plants, manufacturing facilities, utility departments, and industrial electrical contractors handling motors, feeders, and distribution systems. Kamadi Pakistan offers the Fluke 375 FC for professional connected electrical troubleshooting.

Key Features

• True-RMS AC/DC current measurement

• Fluke Connect wireless communication

• Optional iFlex measurement up to 2500 A AC

• Frequency measurement for industrial troubleshooting

• Suitable for VFD and non-linear loads


Technical Specifications

• Model: Fluke 375 FC

• AC Current, Jaw: Up to 600 A

• DC Current: Up to 600 A

• AC Current, iFlex: Up to 2500 A

• AC Voltage: Up to 1000 V

• DC Voltage: Up to 1000 V

• Resistance: Up to 60 kΩ

• Frequency: Up to 500 Hz

• Jaw Opening: 34 mm

• Safety: CAT III 1000 V / CAT IV 600 V


Applications

• Industrial motor troubleshooting

• Electrical distribution testing

• VFD maintenance

• Plant electrical service

• Feeder and load-current checks


Professional Tip: When using iFlex around a single conductor, centre the conductor inside the loop and keep the closing coupling away from adjacent conductors for more consistent current readings.
