Fluke 175 | True-RMS Digital Multimeter for General Electrical Troubleshooting

Not every electrical maintenance task requires temperature measurement or advanced logging, but technicians still need reliable True-RMS performance for modern electrical loads. The Fluke 175 True-RMS Digital Multimeter provides the essential measurement functions of the Fluke 170 Series in a straightforward professional instrument.

It measures AC/DC voltage up to 1000 V, current up to 10 A, resistance, capacitance, and frequency, and provides continuity and diode testing. True-RMS capability improves AC measurement reliability when waveforms are not perfectly sinusoidal. Min/Max/Average recording helps capture signal variations, and manual or automatic ranging lets the technician choose the preferred method. Within the 170 Series, the 175 is the economical choice for users who do not require the backlight and higher DC accuracy of the 177 or the temperature function of the 179.

Fluke 170 Series Selection Guide

Choose the 175 for professional general-purpose electrical testing when you need True-RMS performance but don't need temperature measurement or a backlit display. Move to the 177 for higher DC accuracy or the 179 when temperature testing is also needed.

Market Relevance

The Fluke 175 suits Pakistani electrical contractors, factory maintenance teams, workshops, facility engineers and technical institutes looking for a dependable professional True-RMS meter without unnecessary functions. Buy the Fluke 175 from Kamadi Pakistan for routine electrical troubleshooting.

Key Features

• True-RMS AC measurement

• Manual and automatic ranging

• Min/Max/Average recording

• Frequency and capacitance measurement

• Display Hold and Auto Hold functions


Technical Specifications

• Model: Fluke 175

• DC Voltage: Up to 1000 V

• Basic DC Accuracy: ±0.15%

• AC Voltage: Up to 1000 V

• AC/DC Current: Up to 10 A

• Resistance: Up to 50 MΩ

• Capacitance: Up to 9,999 µF

• Frequency: Up to 99.99 kHz

• Display: 6000 counts

• Safety: CAT III 1000 V / CAT IV 600 V


Applications

• Electrical maintenance

• Equipment troubleshooting

• Panel testing

• Workshop diagnostics

• Electrical installation service


Professional Tip: When testing rapidly changing signals, use Min/Max/Average recording instead of trying to visually follow the live display.
