Fluke 1587 FC | 1kV Insulation Multimeter with Fluke Connect

Motor, cable and electrical-system faults often require both conventional multimeter measurements and insulation testing. Carrying separate instruments increases setup time and makes preventive maintenance work less efficient. The Fluke 1587 FC Insulation Multimeter combines a 1 kV insulation tester with a True-RMS digital multimeter in one handheld instrument.

Insulation test voltages of 50, 100, 250, 500 and 1000 V cover a wide range of equipment, with insulation resistance measurement from 0.01 MΩ to 2 GΩ. The meter also provides AC/DC voltage and current, resistance, continuity, capacitance, frequency, diode and temperature functions. A low-pass filter supports motor-drive measurements. Fluke Connect adds PI/DAR timed-ratio tests, measurement storage and temperature compensation for better condition trending.

Insulation Multimeter Selection Guide

Choose the 1587 FC for technicians needing multiple insulation test voltages, 2 GΩ range, motor-drive filtering, temperature and Fluke Connect diagnostics. The 1577 is better suited to simpler insulation and general electrical testing.

Market Relevance

The Fluke 1587 FC is well-suited for Pakistan's motor workshops, textile mills, cement plants, manufacturing facilities, utilities, and preventive-maintenance teams testing motors, cables, and electrical insulation. Buy the Fluke 1587 FC from Kamadi Pakistan for combined insulation and electrical troubleshooting.

Key Features

• Insulation tester and True-RMS multimeter in one

• Five selectable insulation test voltages

• PI/DAR diagnostics through Fluke Connect

• Low-pass filter for motor-drive testing

• Temperature, frequency and capacitance measurement


Technical Specifications

• Model: Fluke 1587 FC

• Insulation Test Voltages: 50 / 100 / 250 / 500 / 1000 V

• Insulation Resistance: 0.01 MΩ–2.0 GΩ

• Resistance: 0.1 Ω–50 MΩ

• AC/DC Voltage: Yes

• AC/DC Milliamps: Yes

• Capacitance: Yes

• Frequency: Yes

• Temperature: Yes

• Auto-Discharge: Yes


Applications

• Motor insulation testing

• Cable preventive maintenance

• VFD-driven motor troubleshooting

• Electrical equipment commissioning

• Insulation condition trending


Professional Tip: Record insulation temperature with every baseline test; insulation resistance changes significantly with temperature, so uncompensated readings can create misleading maintenance trends.
